Specification
●set top box compliant with MPEG2 , MPEG4, H.264 ,H.265 and AVS
●Compatible with HDTV channels and equipped with HDMI connector
●Supported 7-Day EPG function, VBI Teletext
●Auto search & Blind search & network search function
●Support Media Player
●Support CAS or FTA
Technical Specifications
Core System
Processor : M88CS8001S/M88cs8001T/M88cs8051T
Broadcasttuners: Si2141
Memory: 4MB/8MB Flash/64MB/128MB RAM DDR2
STB up grade: Through OTA or USB Disk
Connectivity
Video:HDMI v1.4a
RCA out (CVBS, Audio LR)
USB:1xUSB2.0 host device
Tuner & Demodulator
Input Frequency: 47MHz-860MHz
Demodulator Partial reception supported
Channel bandwidth: 6M,7M,8MHz
Front panel
- Display:3 LED lndicator, Power Red LED, Lock Green LED
- Button: CH+,CH-
Video Decodin
MPEG4 Simple Profile, Advanced Simple Profile @Level 5 without GMC/Data Partitioning/Reversible VLC
HEVC/H.265 MP@level 4.0 High tier (M88CS8051T only )
MPEG-2 MP@HL
AVS Jizhun profile @ L6.0/4.0/2.0
AVS Broadcast profile @ L6.0/L4.0
H.264 BP (with no ASO/FMO), MP& HP@ L4.1
Setup environment
Function temperature:0-40 degree Celsius
Power consumption: Max 10w
Voltage: 12V/1A
Audio Decoding
- MPEG-1/2 Layer I/II/III
- MPEG-2/4 LC-AAG, MPEG-4 HE-AAC@Level 4
- Dolby AC3/AC3+(Optional)
Dimensions
W x H x D(mm): 168*115*30
Weight(kg):0.5
Packaging dimension(mm):250*170*55
Weight include packaging(kg):0.55
HD/SD Video Encoding
-HD formats: 480p,576p, 720p,1080i/p
-SD formats: NTSC/PAL/SECAM with VBl slicer
Proposed Accessories
Remote control unit
RCA Connect Cable
HDMl Cable
2*7# Batteries
Core System
Processor : M88CS8001S/M88cs8001T/M88cs8051T
Broadcasttuners: Si2141
Memory: 4MB/8MB Flash/64MB/128MB RAM DDR2
STB up grade: Through OTA or USB Disk
Connectivity
Video:HDMI v1.4a
RCA out (CVBS, Audio LR)
USB:1xUSB2.0 host device
Tuner & Demodulator
Input Frequency: 47MHz-860MHz
Demodulator Partial reception supported
Channel bandwidth: 6M,7M,8MHz
Front panel
- Display:3 LED lndicator, Power Red LED, Lock Green LED
- Button: CH+,CH-
Video Decodin
MPEG4 Simple Profile, Advanced Simple Profile @Level 5 without GMC/Data Partitioning/Reversible VLC
HEVC/H.265 MP@level 4.0 High tier (M88CS8051T only )
MPEG-2 MP@HL
AVS Jizhun profile @ L6.0/4.0/2.0
AVS Broadcast profile @ L6.0/L4.0
H.264 BP (with no ASO/FMO), MP& HP@ L4.1
Setup environment
Function temperature:0-40 degree Celsius
Power consumption: Max 10w
Voltage: 12V/1A
Audio Decoding
- MPEG-1/2 Layer I/II/III
- MPEG-2/4 LC-AAG, MPEG-4 HE-AAC@Level 4
- Dolby AC3/AC3+(Optional)
Dimensions
W x H x D(mm): 168*115*30
Weight(kg):0.5
Packaging dimension(mm):250*170*55
Weight include packaging(kg):0.55
HD/SD Video Encoding
-HD formats: 480p,576p, 720p,1080i/p
-SD formats: NTSC/PAL/SECAM with VBl slicer
Proposed Accessories
Remote control unit
RCA Connect Cable
HDMl Cable
2*7# Batteries
