Set Top Box DTMB THS-9100M
型號:THS-9100M
●DTMB-Tset top box compliant with MPEG2 and MPEG4 and H.264 and H.265 and AVS
●Compatible with HDTV channels and equipped with HDMI connector
●EPG & DVB Teletext & DVB Subtitles
●Auto search & Blind search & network search function
●Support Media Player
●Support Dexin CAS
在線咨詢
產品詳情 技術參數 資料下載

Specification

●DTMB-Tset top box compliant with MPEG2 and MPEG4 and H.264 and H.265 and AVS

●Compatible with HDTV channels and equipped with HDMI connector

●EPG & DVB Teletext & DVB Subtitles

●Auto search & Blind search & network search function

●Support Media Player

●Support Dexin CAS


Technical Specifications

Core System
Processor : M88cs8001T /M88CS8051T(High-performance dual MIPS CPU)
Broadcasttuners:
1 DTMB-T

Memory: 8MB Flash SOC Embedded 128MB DDR

STB up grade:Through OTA or USB Disk

Connectivity

Video:HDMl v1.4a
RCA out (CVBs, Audio L/R)

USB: 1xUSB2.0 host device

Tuner & Demodulator
- Input Frequency: 50MHz-860MHz

- Demodulator QPSK,16QAM,64QAM,256QAM demodulationsupported
- Channel bandwidth: 5M,6M,7M,8MHz

Front panel
Display: 3 LED lndicator, Power Red LED, Lock Green LED
Button: VOL+, VOL-, CH+, CH-, Menu, OK

Video Decodin

- MPEG4 Simple Profile, Advanced Simple Profile @Level 5 without GMC/Data Partitioning/Reversible VLC

- HEVC/H.265 MP@level 4.0 High tier (M88CS8051T only )

- MPEG-2 MP@HL

- AVS Jizhun profile @ L6.0/4.0/2.0

- AVs Broadcast profile @ L6.0/L4.0

- H.264 BP(with no ASO/FMO), MP& HP@L4.1

Setup environment
Function temperature:0-40 degree CelsiusPower consumption: Max 10w
Voltage:12V/1A

Audio Decoding

MPEG-1/2 Layer l/II/IIl
MPEG-2/4 LC-AAC, MPEG-4 HE-AAC@Level 4

Dolby AC3/AC3+(Optional)

Dimensions
W x D x H(mm):220*143*43

Weight(kg):0.6
Packaging dimension(mm):240*205*50

Weight include packaging(kg):0.7

HD/SD Video Encoding
-HD formats: 480p, 576p, 720p,1080i/p
-SD formats: NTSC/PAL/SECAM with VBl slicer

Proposed Accessories

-Remote control unit
-RCA Connect Cable OR AAA Batteries



Core System

Processor : M88cs8001T /M88CS8051T(High-performance dual MIPS CPU)
Broadcasttuners:
1 DTMB-T

Memory: 8MB Flash SOC Embedded 128MB DDR

STB up grade:Through OTA or USB Disk

Connectivity

Video:HDMl v1.4a
RCA out (CVBs, Audio L/R)

USB: 1xUSB2.0 host device

Tuner & Demodulator
- Input Frequency: 50MHz-860MHz

- Demodulator QPSK,16QAM,64QAM,256QAM demodulationsupported
- Channel bandwidth: 5M,6M,7M,8MHz

Front panel
Display: 3 LED lndicator, Power Red LED, Lock Green LED
Button: VOL+, VOL-, CH+, CH-, Menu, OK

Video Decodin

- MPEG4 Simple Profile, Advanced Simple Profile @Level 5 without GMC/Data Partitioning/Reversible VLC

- HEVC/H.265 MP@level 4.0 High tier (M88CS8051T only )

- MPEG-2 MP@HL

- AVS Jizhun profile @ L6.0/4.0/2.0

- AVs Broadcast profile @ L6.0/L4.0

- H.264 BP(with no ASO/FMO), MP& HP@L4.1

Setup environment
Function temperature:0-40 degree CelsiusPower consumption: Max 10w
Voltage:12V/1A

Audio Decoding

MPEG-1/2 Layer l/II/IIl
MPEG-2/4 LC-AAC, MPEG-4 HE-AAC@Level 4

Dolby AC3/AC3+(Optional)

Dimensions
W x D x H(mm):220*143*43

Weight(kg):0.6
Packaging dimension(mm):240*205*50

Weight include packaging(kg):0.7

HD/SD Video Encoding
-HD formats: 480p, 576p, 720p,1080i/p
-SD formats: NTSC/PAL/SECAM with VBl slicer

Proposed Accessories

-Remote control unit
-RCA Connect Cable OR AAA Batteries
